Description
|
CPU
|
MT6789 2*A76 2.2GHz，6*A55 2.0GHz
|
|
GPU
|
ARM G57 MC2
|
|
RAM/ROM
|
8GB LPDDR4/ 128GB EMMC
|
|
External Memory
|
Support TF*1,MAX 512GB
|
|
LCD Display
|
10.1“ 16:10,800*1280 IPS LCD, 700 nits
|
|
Touch Panel
|
Multipoints Capacitive，G+G，Rigidity: above 7H-Anti-scratch
|
|
Camera
|
Front:5.0MP, Rear: 13MP auto-facus with flashlight
|
|
Battery
|
3.7V/8000mAh. Built-in polymer lithium ion battery. 8-10 Hrs(default 50% volumn,default maximum lumens brightness,play 1080P HD video)
|
|
Speaker
|
Embedded 8Ω/0.8W waterproof speakerx 1
|
|
Sensor
|
light Sensor *1,Gyro Sensor *1,G_sensor *1,Compass Sensor *1
|
|
Data Collection & Networking
|
|
|
Barcode Scanner
|
2D Optional Honeywell N3680 TTL decoding
|
|
Fingerprint
|
NO
|
|
NFC
|
Build-in NFC, 13.56MHz, ISO/IEC 14443A/B,ISO/IEC 15693, ISO/IEC 18092
|
|
BT
|
BT5.2 (BLE) class1, Transmited distance：10m
|
|
WIFI
|
WIFI 802.11(a/b/g/n/ac) Frequency 2.4G+5.0G dual band WIFI
|
|
4G
|
GSM：2+3+5+8 WCDMA：1+2+5+8 TDD：38+39+40+41N(2535mhz~2655mhz) FDD：1+2+3+4+5+7+8+17+20+28a+28b |
|
GPS
|
Support :GPS+Glonass; Capture sensitivity: -140 dBm; Cool Start Time:less 50second,Hot Start Time:less 28second;
GPS frequency: 1575.42MHz, GLONASS frequency: 1602MHz
|
|
OS
|
Android 11 or 12 With GMS
|
|
I/O Port & Appearance & Package
|
|
|
I/O Port
|
HDMI 1.4a （No Support） Type-c x 1,(Data & Charing) USB 3.0 Type-A x 1, |
|
Dimension
|
275.5*187.5*24mm
|
|
Weight
|
Device unit: 1000g.
|
|
Package
|
USB cable/Handheld Straps/ Charger 5V 3A/Packing box（Can be customized logo)
|
|
Certificate System & Reliability Design
|
|
|
IP67
|
IP65 Report：Water Resistance:IP-X5，Dust Resistance:IP-6X a.Inner Nozzle Diameter：6.3mm；
b. WaterSpeed:12.5±0.625L/min；
c. Water Pressure:Adjust according to water volumnï¼›
d.Central part of water volumn :A round with a diameter of about 40mm at the distance from the nozzle 2.5m.
e.Spray time in surface of panele: About 1 min/Square meterï¼›
f.Test time: at least 3minï¼›
g.Distance between nozzle and panel surface：2.5～3m.
After test,there is no water leakage in sample.
|
|
CE NB
|
YES
|
|
MIL-STD-810G
|
YES
|
|
Battery
|
UN38.3，MSDS,IEC62133
|
|
Drop Height
|
MIL-STD-810G 1.22m drop
|
|
Operate Temperature
|
‘-20 °C to 60 °C
|
|
Store Temperature
|
’-30 °C to 70 °C
|
|
Humidity
|
Humidity: 95% Non-Condensing
|
